| MOQ: | 1 unit |
| Standard Packaging: | Using Carton, fumigated wood pallet and steel pallet |
| Delivery Period: | 45-60 Working days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 5000 units per year |
Used Heavy Truck For Building Construction, Mining, Municipal Construction
C6 Model Advantage
1. Outstanding dynamics
Powerful power: maximum power 287 kW, maximum horsepower 390hp. Strong power output to meet the needs of transportation under different working conditions.
High-efficiency transmission: matched with Faster transmission and double reduction axle, the transmission efficiency is high and the gearshift is smooth, which can effectively reduce driving fatigue, and at the same time, improve the fuel economy and stability of power output.
2.Lightweight design
Structural optimization: through the “material optimization + parts optimization + structural optimization” three major lightweight program, the chassis weight reduction of more than 700kg, the entire vehicle self-mass of ultra-low 8.97t, efficient lightweight not only improves the vehicle's cargo carrying capacity, but also reduces fuel consumption, increasing operating profits.
3. High safety
Body safety: the cab adopts the whole stamping molding, the thickness of steel plate is up to 1.5mm, about 30% thicker than similar products in the industry, which greatly improves the rigidity of the cab body; at the same time, it is equipped with the whole rearward movement technology, adopting the 4-point suspension safety design, in the event of a collision, the cab can be shifted back to the whole of the cab by 500mm, which provides more buffer for the drivers and passengers.
C6 Product Parameters
|
Basic Information |
Description |
|
Drive Type |
6*4 |
|
Wheelbase |
3800+1400mm |
|
Vehicle Length*Width*Height |
8.385m *2.55m * 3.46m |
|
Vehicle Weight |
12.5t |
|
Gross mass |
25t |
|
Rated load |
12.37t |
|
Approach Angle/ Departure Angle |
16°/ 23° |
|
Tonnage Class |
Heavy Truck |
|
Energy type |
2020mm |
|
Front/rear wheelbase |
1858mm/ 1858mm |
|
Engine parameters |
Description |
|
Engine displacement |
8.709L |
|
Maximum Horsepower |
390 hp |
|
Fuel type |
Diesel |
|
Maximum output power |
287kW |
|
Number of cylinders |
6 cylinders |
|
Emission standard |
National Five |
|
Transmission parameters |
Description |
|
Transmission Model |
Fascist 12JSD180T-AL |
|
Forward gear |
12 |
|
Reverse gear |
2 |
|
Cargo compartment parameters |
Description |
|
Cargo compartment length*width*height |
5.6m* 2.3m * 1.5m |
|
Type of cargo compartment |
Self-unloading |
|
Fuel tank |
Description |
|
Fuel tank volume |
400L |
|
Chassis parameters |
Description |
|
Number of spring plates |
8/12 |
|
Rear Axle Description |
HY300M Bridge |
|
Rear axle permissible load |
18000 (2-axle set) kg |
|
Front axle permissible load |
7000kg |
|
Frame Size |
280*(8+4)mm |
|
Front axle description |
7.5T |
|
Tires |
Description |
|
Tire Size |
12.00R20 16PR |
|
Number of tires |
10 |
Detaild pictures
|
|
